1cbm Effective Volume Biomass Carbonization Furnace for Continuous Carbonization Process

Name: 1cbm Effective Volume Biomass Carbonization Furnace for Continuous Carbonization Process
Brand: Mingjie
Price: 120 USD

Quality 1cbm Effective Volume Biomass Carbonization Furnace for Continuous Carbonization Process for sale

Place of Origin : Henan, China

Condition : New

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Hot Product 2023

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Gear, Pump

Brand Name : Mingjie

Effective Volume : 1cbm

Dimension(L*W*H) : L35*W12*H7m

Voltage : Customized

Power : 41.2kw/h

Warranty : 1 Year

Key Selling Points : Long Service Life

Applicable Industries : Food & Beverage Factory, Farms, Energy & Mining

Showroom Location : China

Weight (KG) : 12000

Model : MJT-1000 2000 3000

Raw material : Coconut Shell Wood Sawdust Briquette

Usage : Forestry Biomass Charring Making

Final product : Charcoal Bio-char

Type : Continuous Carbonization

Advantage : Continuous Working Environment Friendly

Capacity : 0.8-1T/H

Color : Customization Support

Certification : CE ISO

Fuel : Firewood Coal Gas Natural Gas

Packaging Details : 20 HC ,40 HC, 40 FR CONTAINER
Small Pyrolysis Machine Convert Plastic tyre to Fuel Mini Biomass Pyrolysis Plant

Port : Qingdao

Supply Ability : 4 Set/Sets per Month

Price : $120,000.00/sets 1-1 sets

MOQ : 1 unit

Contact Now

Product Overview

What is the carbonization?

Biomass carbonization refers to the thermal degradation process of biomass under the environment of high temperature without oxygen, in which volatiles are released and carbon is enriched. The carbonized product is biochar/charcoal, which can be used as soil conditioner or fuel.

1cbm Effective Volume Biomass Carbonization Furnace for Continuous Carbonization Process

PRODUCT SPECIFICATIONS

Model	MJT-500	MJT-1000	MJT-2000	MJT-3000
Reactor Structure	Dual Cylinder	Dual Cylinder	Dual Cylinder	Dual Cylinder
Input Capacity	300-500KG/H	800-1000KG/H	1500-2000KG/H	2500-3000KG/H
Feedstock size	<20mm	<20mm	<20mm	<20mm
Feedstock moisture	<15%	<15%	<15%	<15%
Charcoal output ratio	28-35%	28-35%	28-35%	28-35%
Working Method	Fully Continuous	Fully Continuous	Fully Continuous	Fully Continuous
Fuel Consumption	35-50m³ Natural Gas for initial Heating	40-60m³ Natural Gas for initial Heating	60-80m³ Natural Gas for initial Heating	80-100m³ Natural Gas for initial Heating
Land required	L35W12H6m	L35W12H7m	L45W15H7m	L45W15H7m
Final product	Charcoal/Biochar, Tar&Wood Vinegar, Syngas

FEATURES AT A GLANCE

Final Product & Application

Biochar/Charcoal

1. Used as soil conditioner, carbon sequestration, improve the quality of soil 2. Used as fuel for industry heating and cooling or BBQ 3. Can be reprocessed into activated carbon, widely used in the smelting, chemical fields.

Wood vinegar & tar

Widely used as a crop insecticide, make leaf surface fertilizer

Syngas

1. Can be recycled to heat the carbonization host. 2. By this way, you can reduce a lot of fuel costs.

Successful Project

Project in Japanese

Project in Tanzania

Project in China

1cbm Effective Volume Biomass Carbonization Furnace for Continuous Carbonization Process Images
